The WALT 10kW Yangdong-powered diesel generator is a cost-effective prime power solution for export markets, designed to deliver 10kW prime output under both 50Hz and 60Hz configurations, depending on system setup.
Unlike some engine platforms where the 10kW class is available only in 50Hz prime-rated configurations, the Yangdong engine range allows this power level to be configured as 10kW prime power at either 50Hz or 60Hz, offering greater flexibility at the model selection stage.
Powered by a Yangdong water-cooled industrial diesel engine, this generator is suitable for prime and continuous operation under defined load conditions and maintenance schedules. It has been supplied for telecom base stations, small commercial facilities, and distributed power applications, where reliability and controlled operating cost are key considerations.
Electrical output can be configured as single-phase or three-phase, with voltage options customized according to destination country requirements (e.g., 230/400V, 127/220V).
Specifications
50Hz
60Hz
50Hz
Genset Model
WGP-Y13/S
Prime Output (PRP)
10 kW / 13 kVA
Standby Output (ESP)
11 kW / 14 kVA
Engine
Yangdong YD480D
Alternator
Walt
Voltage
380/400/415V
Frequency – speed
50Hz – 1500 rpm
Phase
3-phase (1-phase is optional)
Type
Silent with a soundproof canopy
Controller
UK Deep Sea
Starting Method
Auto Start
Fuel Tank capacity
1000 Liters
Fuel Consumption @100% Load (PRP)
3.5 L/H
Fuel Consumption @75% Load (PRP)
2.6 L/H
Continuous Running Time
Depends on fuel tank capacity and load conditions
Dimensions (L × W × H)
2000×950×1880 mm
Genset Weight
1050 Kg
Fuel tank capacity shown is for the reference configuration only. Actual tank size may vary depending on project requirements and final configuration.
* Specifications and configurations are subject to change as part of continuous product improvement.
* Dimensions, weight, and technical parameters may vary depending on final configuration and destination market requirements.
* This information is provided for reference only. Final specification will be confirmed upon order confirmation.
* For pricing, configuration options, and lead time, please contact:
Technical & Procurement FAQ
Q1: Is this 10kW Yangdong diesel generator suitable for prime power operation?
A: Yes. This model is designed and configured to deliver 10kW prime power output under defined load conditions and maintenance schedules.
Depending on system configuration, it can be supplied as 10kW prime power at 50Hz or 10kW prime power at 60Hz, making it suitable for continuous-duty applications, including telecom base stations and distributed power sites.
Q2: What is the difference between this Yangdong-powered generator and other engine options in the same power range?
A: The main difference lies in engine model availability and power matching, particularly under 60Hz prime power requirements.
In the 10kW power range, some engine platforms do not offer a directly matched 10kW prime-rated configuration at 60Hz. Available options may fall below or above this power level, which can lead to undersizing risks or higher system cost, depending on the application.
The Yangdong engine platform allows this generator to be configured as 10kW prime power at both 50Hz and 60Hz, enabling more precise power matching and a cost-effective solution for export markets, telecom sites, and distributed power applications.
Brand Statement
WALT Power is an independent China-based diesel generator manufacturer and exporter, specializing in industrial generator sets for export markets.
All Yangdong-powered generator sets supplied by WALT Power are configured with brand-new, genuine Yangdong diesel engines and are assembled to meet destination market requirements and applicable standards.
With over a decade of export experience, WALT Power focuses on reliable configurations, transparent specifications, and long-term serviceability for distributors, telecom operators, EPC contractors, and project buyers.
60Hz
Genset Model
WGP-Y13/S6
Prime Output (PRP)
10 kW / 13 kVA
Standby Output (ESP)
11 kW / 14 kVA
Engine
Yangdong YD385D
Alternator
Walt
Voltage
220/230/240/440/460/480V
Frequency – speed
60Hz – 1800 rpm
Phase
3-phase (1-phase is optional)
Type
Silent with a soundproof canopy
Controller
UK Deep Sea
Starting Method
Auto Start
Fuel Tank capacity
1000 Liters
Fuel Consumption @100% Load (PRP)
3.3 L/H
Fuel Consumption @75% Load (PRP)
2.5 L/H
Continuous Running Time
Depends on fuel tank capacity and load conditions
Dimensions (L × W × H)
2000×950×1880 mm
Genset Weight
1020 Kg
Fuel tank capacity shown is for the reference configuration only. Actual tank size may vary depending on project requirements and final configuration.
* Specifications and configurations are subject to change as part of continuous product improvement.
* Dimensions, weight, and technical parameters may vary depending on final configuration and destination market requirements.
* This information is provided for reference only. Final specification will be confirmed upon order confirmation.
* For pricing, configuration options, and lead time, please contact:
Technical & Procurement FAQ
Q1: Is this 10kW Yangdong diesel generator suitable for prime power operation?
A: Yes. This model is designed and configured to deliver 10kW prime power output under defined load conditions and maintenance schedules.
Depending on system configuration, it can be supplied as 10kW prime power at 50Hz or 10kW prime power at 60Hz, making it suitable for continuous-duty applications, including telecom base stations and distributed power sites.
Q2: What is the difference between this Yangdong-powered generator and other engine options in the same power range?
A: The main difference lies in engine model availability and power matching, particularly under 60Hz prime power requirements.
In the 10kW power range, some engine platforms do not offer a directly matched 10kW prime-rated configuration at 60Hz. Available options may fall below or above this power level, which can lead to undersizing risks or higher system cost, depending on the application.
The Yangdong engine platform allows this generator to be configured as 10kW prime power at both 50Hz and 60Hz, enabling more precise power matching and a cost-effective solution for export markets, telecom sites, and distributed power applications.
Brand Statement
WALT Power is an independent China-based diesel generator manufacturer and exporter, specializing in industrial generator sets for export markets.
All Yangdong-powered generator sets supplied by WALT Power are configured with brand-new, genuine Yangdong diesel engines and are assembled to meet destination market requirements and applicable standards.
With over a decade of export experience, WALT Power focuses on reliable configurations, transparent specifications, and long-term serviceability for distributors, telecom operators, EPC contractors, and project buyers.
