√. ISO container construction
√. Ruggedly constructed and designed for continuous operation
√. Typical containers are available in 20 and 40 feet and specialized control rooms to keep the components weatherproof
√. Provide the operator with a safe and secure work area
√. Transportable, containerized load banks are perfect for large capacity load testing
√. Wide voltage range
√. Optional multi-function intelligent controls
√. Remote, local, or PC Control
√. 12 months of warranty
WALT lines of stationary, indoor, or outdoor high voltage resistive load banks are designed and built to be permanently mounted and used for dedicated, on-site testing. Load banks up to 10.5k in 50/60Hz can be supplied either fan-forced or naturally ventilated. Using an 11kV load bank directly connected to an 11kV generator or turbine means that a transformer is not required as part of the load bank package and is often a cost-efficient method. Ratings up to 5MW are available.
| Load Bank Model | Power | Power | Load Voltage | Frequency | Dimension | Weight |
| kW | Factor | kV | Hz | mm | Kg | |
| WGP-LB-10.5kV-2000KW | 2000 | 1 | 10.5 | 50 | 6100*2450*2600 | 6000 |
| WGP-LB-10.5kV-3000KW | 3000 | 1 | 10.5 | 50 | 9150*2450*2600 | 8000 |
| WGP-LB-10.5kV-5000KW | 5000 | 1 | 10.5 | 50 | 12100*2450*2600 | 10000 |
1. The specifications are subject to change without notice
2. The size parameters are subject to the kind
3. Send an email to sales@waltpower.com to get a detailed quote
| Load Bank Model | Power | Power | Load Voltage | Frequency | Dimension | Weight |
| kW | Factor | kV | Hz | mm | Kg | |
| WGP-LB-10.5kV-2000KW | 2000 | 1 | 10.5 | 60 | 6100*2450*2600 | 6000 |
| WGP-LB-10.5kV-3000KW | 3000 | 1 | 10.5 | 60 | 9150*2450*2600 | 8000 |
| WGP-LB-10.5kV-5000KW | 5000 | 1 | 10.5 | 60 | 12100*2450*2600 | 10000 |
1. The specifications are subject to change without notice
2. The size parameters are subject to the kind
3. Send an email to sales@waltpower.com to get a detailed quote
WALT Global Power Equipment Co., Ltd is a top China supplier & manufacturer of Cummins Emergency Backup Silent Generator, 3 Phase Generator, Perkins Generator, Portable Generator, Industrial Generator & Load Banks.
We will contact you within 1 working day, please pay attention to the email with the suffix “@waltpower.com”.
